TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+ – 2
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+ – 3
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+ – 4
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+ – 5
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+
TP-Link Omada 5-Port Gigabit Easy Managed Switch with 4-Port PoE+

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

TP-Link Omada 5-Port Gigabit Easy Managed Switch

31.74 €
3356541

ES205G

8885020620917, 0810142820424, 8885020620924

Shipping 2-3 b.d.

You are interested in this product?
(Read terms of service)

All about the product

The TP-Link Omada ES205G is a compact and silent 5-Port Gigabit Easy Managed Switch designed for small businesses, offices, and professional environments. With robust Layer 2 features, centralized Omada SDN management, and fanless operation, it delivers reliable performance in a durable and flexible form factor.

Hardware Features

  • 5× 10/100/1000 Mbps RJ45 Ports with Auto-Negotiation and Auto MDI/MDIX

  • Fanless design for silent operation

  • Flexible installation: desktop or wall-mount

  • Physical security lock for enhanced protection

  • External power supply: 5 VDC / 0.6 A

  • Compact dimensions: 3.9 × 3.9 × 1.0 in (100 × 98 × 25 mm)

  • Surge protection up to ±6 kV

Performance

  • Switching capacity: 10 Gbps

  • Packet forwarding rate: 7.4 Mpps

  • MAC address table: 8K entries

  • Packet buffer: 4 Mbits

  • Jumbo frame support: up to 15 KB

  • Transmission method: Store-and-Forward

Software Features

  • Quality of Service (QoS)

    • Port-based / 802.1p / DSCP QoS

    • 8 priority queues with WRR scheduling

    • Bandwidth control per port

    • Storm control (broadcast, multicast, unknown-unicast)

  • Layer 2 features

    • Static link aggregation

    • Loop prevention and loopback detection

    • 802.3x flow control

    • Port mirroring (one-to-one, many-to-one, ingress/egress/both)

    • Port statistics and LLDP (802.1ab)

  • Layer 2 multicast

    • IGMP snooping v1/v2/v3 with fast leave

  • VLAN

    • MTU VLAN, port-based VLAN

    • 802.1Q tag VLAN (up to 32 VLAN groups, 4K VID)

Management

  • Centralized control via Omada SDN

    • Supported controllers: Omada Hardware, Cloud-Based, or Software Controller

  • Omada App support for mobile management

  • Cloud access for remote monitoring and configuration

  • Zero-Touch Provisioning (ZTP) with cloud-based controller

  • Management features:

    • Web-based GUI

    • DHCP client

    • Cable diagnostics

    • Automatic device discovery

    • Batch configuration & firmware upgrading

    • Unified configuration

Other Information

  • Certifications: FCC, CE, RoHS

  • Package contents: ES205G switch, power adapter, installation guide, rubber feet

  • Operating environment:

    • Temperature: 0–40 °C (32–104 °F)

    • Storage: –40–70 °C (–40–158 °F)

    • Humidity: 10%–90% (operating), 5%–90% (storage), non-condensing

Design
LED indicators Yes
Product colour Black
Power
Power over Ethernet (PoE) No
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -40 - 70 °C
Operating relative humidity (H-H) 10 - 90%
Storage relative humidity (H-H) 5 - 90%
Weight & dimensions
Width 100 mm
Depth 98 mm
Height 25 mm
Packaging data
Package type Box
Technical details
Compliance certificates CE, RoHS, Federal Communications Commission (FCC)
