PowerWalker VFI 1000 RMG PF1 uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 100
PowerWalker VFI 1000 RMG PF1 uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 100
PowerWalker VFI 1000 RMG PF1 uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 100

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

PowerWalker VFI 1000 RMG PF1 uninterruptible power supply (UPS) Double-conversion (Online) 1 kVA 1000 W

465,89 €
Monthly payment from 12.90
1806778

10122112

4260074979954

Shipping 6-8 b.d.

Quantity
You are interested in this product?
(Read terms of service)
The PowerWalker VFI 1000-3000 RMG PF1 is a professional series for commercial applications featuring unity Power Factor (PF=1.0) and very strong charger with adjustable current. The wide input voltage and frequency ranges allow operation in unstable networks and provide generator support.

Multiple accessories, including battery packs and communication cards, enhance the functionality of the UPS and allow a greater backup time. The system can be monitored locally via an LCD panel or remotely via the PowerWalker ViewPower software. With its slim design it only requires 2U valuable space of your rack system. The UPS can be installed in 19” rack systems or used as tower.
Product colourBlack
USB 2.0 ports quantity1
Display typeLCD
USB portYes
Form factorRackmount
Weight14.1 kg
Width438 mm
Depth410 mm
Height88 mm
Cables includedUSB cable; Input power cable; Output power cable
Package typeBox
Package width500 mm
Package depth560 mm
Package height180 mm
Package weight17.6 kg
Number of batteries supported3
Warranty cardYes
ManualYes
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)20 - 95%
Ethernet LAN (RJ-45) ports1
Battery recharge time3 h
Battery voltage12 V
Battery capacity7 Ah
Power factor0.99
Noise level50 dB
Surge protectionYes
Output power1000 W
Harmonized System (HS) code85078000
Rack capacity2U
RS-232 ports1
Serial interface typeRS-232
Serial interfaceYes
UPS topologyDouble-conversion (Online)
Output power capacity1 kVA
WaveformSine
Input operation voltage (min)110 V
Input operation voltage (max)300 V
Input frequency40/70 Hz
Output operation voltage (min)200 V
Output operation voltage (max)240 V
Crest factor3:1
Emergency Power Off (EPO)Yes
AC outlet typesC13 coupler
Power plugC14 coupler
Typical backup time at full load4.5 min
Typical backup time at half load12.9 min
Output voltage Total Harmonic Distortion (THD)2%
Input current Total Harmonic Distortion (THD)1.6%
Bundled softwareViewPower / ViewPowerMini
Surge protection featuresNetwork; Modem; Fax
Modem (RJ-11) ports1
Output voltage regulation1%
Resource CDYes
Number of type F outputs8
Emergency Power Off (EPO) connectorYes
