Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C
Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C
Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C
Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C
Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C
Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Extra Digital USB3.2 Gen1 extender up to 100m, 2xUSB-A, 2xUSB-C

219,00 €
Monthly payment from 6.54 €
4023393

CA916054

9990000916054

Shipping 2-4 days

Quantity

You are interested in this product?
(Read terms of service)
USB3.2 Gen1 signal extender over CAT6A up to 100m, 2xUSB-A, 2xUSB-C, 1xRJ45USB 3.2Gen1 signal extender designed for high-speed data and USB interface signal transmission via CAT6A cable over network infrastructure up to 100m. The receiver is equipped with 2 USB Type-A and 2 USB Type-C ports. The set includes a transmitter (TX) and a receiver (RX), powered by 12V/2A adapters.
Features:USB 3.2Gen1 signal and Ethernet transmission via CAT6A cable up to 100 meters.USB 3.2Gen1 data transfer speed up to 5 Gbps.When using double-shielded CAT6A network cable, the USB connection can be extended up to 100 meters.Receiver with 2 USB Type-A and 2 USB Type-C ports, supporting all USB 3.0, 2.0 and 1.1 devices.Suitable for use with USB printer, flash drive, external hard drive, motion control devices, camera, touch screen, keyboard and mouse, USB to video or audio converter and other devices.Each receiver USB port current up to 1.5 A (7.5 W), with a maximum total power of four USB ports not exceeding 21 W.Transmitter and receiver point-to-point connection.Full metal housing ensures excellent heat dissipation and more stable operation.Simple plug and play connection, no additional software required.Supports major operating systems: Windows, MacOS, Linux and Chrome OS.Reliable solution to extend USB 3.0 devices up to 100 m without speed loss.
Technical specifications:Max. (CAT6 cable) length between transmitter and receiver: 100m.Unshielded cable length between transmitter and receiver: 50m.RJ45 Ethernet port: 100 / 1000 Mbps.Max. data transfer rate: 5Gbps.Power adapter: AC (50Hz, 60Hz) 100V-240V; DC 12V /2A.Operating current: 0.2 A.Max. operating current (when no USB devices are connected): 300 mA.USB port maximum current: 1.5 A (per port).Operating temperature: 0°C ~ +45°C.Operating humidity: 5-90%RH (non-condensing).Dimensions: 104x103x28 mm.Weight: TX 171g; RX 177g.
Transmitter ports:DC/12V - power input port.Red power indicator light.PWR / SRC - 12V DC / USB Type-C power selector.HOST - connection to the computer (host) USB port.Blue Type-C 3.0 insertion indicator light.Blue operation indicator light.TX - RX (Phoenix terminal): RS232 serial port.FSYNC - synchronous signal (1.8V) control end.HDBT–USB3 - network port.Receiver ports:DC/12V - power input port.Blue USB equipment identification indicator light.DEVICE / USB 3.0 - USB3.2Gen1 interface. (2x USB Type-A, 2x USB Type-C).HDBT-USB3 - network port.Blue operation indicator light.TX - RX (Phoenix terminal): RS232 serial port.FSYNC - synchronous signal (1.8V) control end.Red - power indicator light.
Warranty: 24 months
