Toote toon ja tegelik värvus võivad erineda pildil kujutatust, kuna pildid on illustratiivse iseloomuga. Samuti on toote kirjeldus üldine ega pruugi sisaldada kõiki toote omadusi.

Power over Ethernet HAT (B), 802.3af PoE and network adapter for Raspberry Pi 3B+/4B, Waveshare 18014

39.00 €
Kuumakse alates 1,90 €
3672101

AN-19592

5903351247757

Tarneaeg 11-18 t.p.

Kauba vastu huvi?
(Lugege teenusetingimusi)

Kõik toote kohta

The Power over Ethernet HAT (B) is a add-on module designed for the Raspberry Pi 3B+ and 4B minicomputers. It provides both 802.3af network connectivity and power to the Raspberry Pi over Ethernet. The PoE input voltage must be between 37V and 57V. The add-on has an easy-to-read 0.9” display that displays temperature, IP address, and fan status (built into the add-on). It is equipped with a PCF8574 chip and an SSD1306 controller. For proper Power over Ethernet operation, the HAT requires a router/switch with PoE (Power over Ethernet) capability.

Specifications:
  • Type: power module
  • Embedded circuit: PCF8574
  • Compatible with Raspberry Pi version 3B+ / 4B
  • PoE power supply: 37 V to 57 V DC
  • PoE output power: 5V/2.5A DC 5.5/2.5mm
  • Network standard: 802.3af PoE
  • Screen:
    • type: OLED display
    • diagonal: 0.9"
    • resolution: 128x32px
    • built-in controller: SSD1306
    • value display color: white
  • Module dimensions: 56.5 mm x 65 mm
Included:
  • Power over Ethernet HAT (B) - PoE and 802.3af power adapter
  • Installation elements:
    • gasket - x4
    • screw - x4
    • cover - x4
