Lindy HDMI 4K30 Audio Extractor
60,69 €
Monthly payment from 2.46 €
1136226 38167
4002888381673
Shipping 2-3 b.d.
You are interested in this product?
The extractor supports high quality 4096x2160@30Hz resolutions with additional pass-through support for CEC, to allow source devices to be controlled from a TV control, and HDCP 1.4, this is ideal for use with source devices such as set top boxes, games consoles and Blu-Ray Players.
This audio extractor allows output to both digital formats via Optical and HDMI and analogue via L/R connections, ensuring seamless compatibility with an amplifier, sound bar or 2-channel speaker setup. With support for multi-channel audio including DTS: HD and Dolby Digital 5.1, this device will ensure an impressive three-dimensional surround sound performance to compliment films, games and music when connected to an audio device. The 3.5mm analogue connection ensures 2-channel speaker set ups can also be connected to the extractor.
Featuring a neat switch to fully control which source audio EDID is used and the ability to be powered via USB from the source or display device, the extractor provides simple use and installation, great for both AV installations in the home or in commercial settings. With a minimalist and stylish design, it can also be hidden out of sight to compliment the popular trend of discreet AV installations.
| Product colour | Black |
| Weight | 118 g |
| Width | 65 mm |
| Depth | 88 mm |
| Height | 24 mm |
| Cables included | DC to USB Type-A |
| Package type | Box |
| Package width | 202 mm |
| Package depth | 144 mm |
| Package height | 55 mm |
| Maximum resolution | 4096 x 2160 pixels |
| Package weight | 250 g |
| Manual | Yes |
| Chipset | EP91A2E |
| Certification | CE, UKCA, FCC, RoHS, REACH |
| Operating temperature (T-T) | -15 - 55 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| DC-in jack | Yes |
| Housing material | Metal |
| Power consumption (typical) | 5 W |
| Maximum data transfer rate | 10200 Mbit/s |
| Quantity | 1 |
| Digital audio optical out | 1 |
| Digital audio coaxial out | 1 |
| HDMI version | 1.4 |
| HDCP | Yes |
| Harmonized System (HS) code | 85176990 |
| S/PDIF out port | Yes |
| HDCP version | 1.4 |
| Input impedance | 100 Ω |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Digital audio optical in | 0 |
| Digital audio coaxial in | 0 |
| Audio (L/R) out | 1 |
| Output impedance | 100 Ω |
| Audio codecs | Dolby Digital 2/5.1, DTS-HD |
| Audio recording formats | LPCM |
| USB 1.1 ports quantity | 0 |
| Supported sample rates | 192 kHz |
| CEC pass-through | Yes |
| Power note | 5.5/2.1mm DC |
| HDMI pass-through | Yes |
| Supported chroma subsampling | 4:4:4 |
| Accuracy | 0.1 dB |
| Compliance certificates | RoHS; REACH |
