Bluetooth Low Energy module (BLE 4.0), NRF51822, Waveshare 9515

19.00 €
3652158

AN-04505

5904422371531

Tarneaeg 11-18 t.p.

Kauba vastu huvi?
(Lugege teenusetingimusi)

Kõik toote kohta

Communication module operating in the Bluetooth BLE 4.0 standard, up to 30 meters away. Unlike classic BT, BLE has no legal restrictions, iOS applications can be freely developed and shared. It has a built-in PCB antenna.

Specifications:

  • Controller: nRF51822 based ARM Cortex-M0 32-bit system
  • Operating frequency: 2.4 GHz
  • Supply voltage: 2.0 to 3.6 V
  • Distance: 30 m
  • Flash memory: 256 KB
  • RAM: 32 KB
  • Interfaces: SPI, I2C, UART
  • Integrated ADC - 10-bit
  • Power setting: -20 dBm to 4 dBm
  • Built-in PCB antenna
  • Terminal pitch: 2 mm
  • Dimensions: 33 x 25 mm

Links:
Manufacturer's page
Manual
