DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A – 2
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A – 3
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A – 4
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A
DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A

Toote toon ja tegelik värvus võivad erineda pildil kujutatust, kuna pildid on illustratiivse iseloomuga. Samuti on toote kirjeldus üldine ega pruugi sisaldada kõiki toote omadusi.

DFRobot DFR0205 voltage regulator, converts 3.3 V - 25 V 5 A

22.73 €
3572225

AN-15090

5904422323219

Tarneaeg 11-18 t.p.

Kauba vastu huvi?
(Lugege teenusetingimusi)

Kõik toote kohta

Inverter module designed to convert input voltage from 3.6 V to 25 V to output voltage from 3.3 V to 25 V. 5 V current capacity 5 A. The input voltage must be higher than the output voltage. The module has three different output interfaces.

Specifications:

  • Input voltage: 3.6V to 25V
  • Output voltage: adjustable from 3.3V to 25V
  • Output current: 5 A at 5 V
  • Maximum output power: 25 W
  • Switching frequency: 350 kHz
  • Three different output interfaces:
    • ARK connectors
    • gold pin
    • JST connector pitch 2.54 mm
  • One interface for initial output voltage
  • Dimensions: 50 x 46 x 20 mm

Links:
Manufacturer's page
Manual
