IP Camera | IPC-B120HA-LU | Bullet | 2 MP | 2.8mm | IP67 |

Kõik toote kohta

• Camera
• Sensor 1/2.9" Progressive Scan CMOS
• Max resolution 1920 × 1080
• Min. illumination Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
• Shutter speed 1/3 s to 1/100,000 s
• Day & Night IR cut filter
• Angle change Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360°

• Lens
• Lens type Fixed focal lens, 2.8 and 4 mm optional
• Focal Length & FOV

  2.8 mm, horizontal FOV 103°, vertical FOV 56°, diagonal FOV 121°

  4 mm, horizontal FOV 83°, vertical FOV 44°, diagonal FOV 99°

• Lens mount M12
• Iris type Fixed
• Aperture F1.6

• DOROUS
• DOROUS

  2.8 mm, D: 45 m, O: 18 m, R: 9 m, I: 4 m

  4 mm, D: 56 m, O: 22 m, R: 11 m, I: 5 m

• Lighting
• Additional lighting type IR,White Light
• Additional lighting range Up to 30 m
• Smart additional lighting Yes
• IR wavelength 850 nm

• Image
• Main stream

  50Hz: 25fps (1920×1080, 1280×720)

  60Hz: 30fps (1920×1080, 1280×720)

• Secondary flow

  50Hz: 25fps (640×480, 640×360)

  60Hz: 30fps (640×480, 640×360)

• Image compression

  Main stream: H.265+/H.265/H.264+/H.264,

  Sub-stream: H.265/H.264/MJPEG

• Video bitrate 32 Kbps to 8 Mbps
• H.264 type Baseline Profile, Main Profile, High Profile
• H.265 type Main Profile
• Bit rate control CBR,VBR
• Region of Interest (ROI) 1 fixed region for main stream

• Sound
• Sound type Mono sound
• Noise cancellation Yes
• Audio sampling frequency 8 kHz/16 kHz
• Audio compression G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC
• Audio bit rate 64 Kbps (G.711 ulaw/G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC)

• Internet
• Security Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address)
• Live video viewing Up to 6 channels
• API Open Network Video Interface (Profile S, Profile T), ISAPI, SDK
• Protocols TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP
• User/Host

  Up to 32 users

  3 user levels: administrator, operator, and user

• Client iVMS-4200, HiLookVision
• Browser

  Plug-in required live view: IE 10, IE 11,

  Local service: Chrome 57.0+, Firefox 52.0+

• Photo
• Wide Dynamic Range (WDR) Digital WDR
• SNR ≥ 52 dB
• Day/Night mode Day,Night,Auto,Schedule
• Photo enhancement BLC,HLC,3D DNA
• Photo settings Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
• Privacy mask 4 programmable polygon privacy masks

• Interface
• Internet interface 1 RJ45 10M/100M self-adaptive Ethernet port
• Built-in microphone Yes

• Features
• Main functions Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception
• Interface Upload to FTP, send email, notify surveillance center, trigger capture

• Home
• System parameters

  12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug, reverse polarity protection,

  PoE: IEEE 802.3af, Class 3, max. 6.5 W

• Material Metal & Plastic
• Size 184.1 mm × 66 mm × 69.1 mm (7.3" × 2.6" × 2.7")
• Package size 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
• Weight Approx. 265 g (0.6 lb.)
• Weight with packaging Approx. 495 g (1.1 lb.)
• Storage conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Operating conditions -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
• Language English, Ukrainian
• Main functions Heartbeat, anti-banding, mirror, password protection, password reset via email

• Approvals
• EMC

  FCC: 47 CFR Part 15, Subpart B,

  CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,

  RCM: AS/NZS CISPR 32: 2015,

  IC: ICES-003: Issue 7

• Security

  CB: IEC 62368-1: 2014+A11,

  CE-LVD: EN 62368-1: 2014/A11: 2017

• Environmental protection

  CE-RoHS: 2011/65/EU,

  WEEE: 2012/19/EU,

  Reach: Regulation (EC) No 1907/2006

• Protection IP67: IEC 60529-2013
