Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400 – 2
Bottom connection radiator Purmo CV 22, 600-1400 – 3
Bottom connection radiator Purmo CV 22, 600-1400 – 4
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400
Bottom connection radiator Purmo CV 22, 600-1400

Toote toon ja tegelik värvus võivad erineda pildil kujutatust, kuna pildid on illustratiivse iseloomuga. Samuti on toote kirjeldus üldine ega pruugi sisaldada kõiki toote omadusi.

Bottom connection radiator Purmo CV 22, 600-1400

229.00 €
Kuumakse alates 6,80 €
2921397

F072206014011300

5907814707932

Tarneaeg 10-14 t.p.

Kauba vastu huvi?
(Lugege teenusetingimusi)

Kõik toote kohta

Bottom connection radiator with thermostatic element

Top quality product
Two profiled panels, two convectors
Height from 300 mm to 900 mm
Length from 400 mm to 3000 mm
Power from 384W to 7164W (75º/ 65º / 20º )
Connection at the bottom, standard from the right
A thermostatic element is installed
The set includes wall brackets, a blind and a drainer

lower-connection-radiator-purmo-cv

Purmo Ventil Compact

A compact radiator is a classic panel radiator that meets the highest quality and efficiency requirements. If all the pipes are visible in traditional radiators, the top and side covers in compact radiators give them a pleasant and attractive appearance. And the choice of models is as extensive as all our panel radiators.

Compact radiators can be of several different types, which you can perfectly adapt to your room. The Ventil model is a variant of the classic compact radiator. In this radiator, all pipes and valves are hidden inside the radiator, giving it a subtle and uncluttered look.

Technical data

Universal PURMO Ventil Compact radiators with profiled panels and convection elements, with side hoods and top grill. Two connections at the bottom and four at the side, internally threaded G ½", allow connection from the bottom and, if necessary, from the side. Radiator with Oventrop pre-regulating thermostatic valve.

  • Material: high-quality stamped stainless steel sheet FePO 1 according to EN 10130
  • Pitch of vertical water channels: 33.3 mm
  • Connections: 2 x G ½ " on the right of the lower connection (on the left - on request), 4 x G ½ " of the side connection
  • Working pressure: 10 bar
  • Maximum temperature: 110 °C
  • Test pressure: 13 bar
  • Color: white RAL 9016, other colors of the RAL palette - on request
  • Accessories: fasteners, blind, air valve (included in the set)
