Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083
Arduino Nano ESP32 with connectors - ABX00083

Toote toon ja tegelik värvus võivad erineda pildil kujutatust, kuna pildid on illustratiivse iseloomuga. Samuti on toote kirjeldus üldine ega pruugi sisaldada kõiki toote omadusi.

Arduino Nano ESP32 with connectors - ABX00083

30,89 €
2873930

ABX00083

7630049203969

Kaup saabub Tallinna lattu 07.07.26

Kogus

Kauba vastu huvi?
(Lugege teenusetingimusi)
Arduino Nano ESP32 has a well-known, efficient system - ESP32-S3. It combines support for the Arduino ecosystem with ESP capabilities and support for Arduino and MicroPython. The module provides unlimited possibilities for creating IoT projects thanks to WiFi and Bluetooth connectivity. This version of the board has pre-soldered connections. Up to 240 MHz clock speed, the u-Blox NORA-W106 (ESP32-S3) chip has 384 kB ROM and 512 kB SRAM memory. The board also includes 128MB (16MB) of external Flash memory.

Main features:
  • The Arduino Nano ESP32 board is based on previous models in the Nano family, making it ideal for compact projects
  • Equipped with an ESP32-S3 chip that provides WiFi and Bluetooth wireless connectivity, making it an ideal solution for IoT projects
  • Change language seamlessly from Arduino to MicroPython in a few simple steps. For more information on programming with MicroPython, see the documentation
  • Create IoT projects quickly and easily with just a few lines of code. The Arduino IoT Cloud app keeps you safe by allowing you to monitor and control your IoT project from anywhere
  • Enables mouse and keyboard emulation via USB. This feature allows you to create new ways of interacting with your computer
  • The board supports debugging via Arduino IDE 2, no external modules are required
Specifications:
  • Chip: u-blox NORA-W106 (ESP32-S3)
  • Clock speed: up to 240 MHz
  • ROM memory: 384 KB
  • SRAM memory: RAM: 512 KB
  • External Flash memory: 128 MB (16 MB)
  • Connector: USB Type-C
  • Pins:
    • integrated LED: pin 13
    • 14x digital inputs/outputs
    • 8x analog inputs
    • 5x PWM
    • external interrupts on all digital pins
  • Wireless connection: WiFi / Bluetooth
  • Interfaces:
    • UART: 1x, D0 (TX), DC (RX)
    • I2C: 1x, A4 (SDA), A5 (SCL)
    • SPI: D11 (COPI), D12 (CIPO), D13 (SCK), any GPIO as CS
  • I/O voltage: 3.3V
  • Supply voltage: 5V to 18V
  • Source current per I/O pin: 40 mA
  • Current per I/O pin: 28 mA
  • Dimensions: 45 x 18 m
