Shuttle DL40N PC/workstation barebone
299,00 €
Monthly payment from 8.60 €
4244570 DL40N
0887993008066
This product is no longer in stock
You are interested in this product?
Connectivity is at the heart of the DL40N. Featuring dual Intel 2.5G LAN ports for high-speed networking and an optional 4G upgrade, it ensures seamless integration even in mobile or remote applications. The integrated Intel UHD Graphics supports hardware acceleration for 4K video playback across three independent displays (HDMI, DisplayPort, VGA), making it a versatile choice for digital signage and multi-monitor office environments.
Designed for 24/7 continuous operation and encased in a durable metal chassis, the DL40N remains noiseless when paired with an SSD. Whether it’s for industrial control, point-of-sale, or silent office use – the DL40N delivers professional-grade performance in a compact, maintenance-free form factor.
| Operating system installed | No |
| Wi-Fi | No |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 75 mm |
| HDMI ports quantity | 1 |
| USB 2.0 ports quantity | 0 |
| Processor model | N150 |
| Processor cores | 4 |
| Weight | 800 g |
| Width | 165 mm |
| Depth | 190 mm |
| Height | 43 mm |
| AC adapter included | Yes |
| Memory voltage | 1.1 V |
| Cooling type | Passive |
| Maximum resolution | 4096 x 2160 pixels |
| Package weight | 2.1 kg |
| Sustainability certificates | ENERGY STAR; ErP |
| Windows operating systems supported | Windows 10; Windows 11 x64 |
| Quick start guide | Yes |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| DC-in jack | Yes |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 2 |
| Card reader integrated | No |
| LED indicators | Power; HDD |
| Housing material | Steel |
| AC input voltage | 100 - 240 V |
| Drivers included | Yes |
| Product type | Mini PC barebone |
| Built-in speaker(s) | No |
| On/off switch | Yes |
| AC input frequency | 50/60 Hz |
| Number of displays supported | 3 |
| Number of storage drives supported | 2 |
| HDMI version | 2.0b |
| Power supply type | External AC adapter |
| Thermal Design Power (TDP) | 6 W |
| Linux operating systems supported | Yes |
| NVMe | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Power supply | 65 W |
| Built-in processor | Yes |
| Processor manufacturer | Intel |
| Processor boost frequency | 3.6 GHz |
| Processor cache | 6 MB |
| Maximum internal memory | 16 GB |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | Intel® Graphics |
| Chassis type | 1.35L sized PC |
| Trusted Platform Module (TPM) | Yes |
| DisplayPorts quantity | 1 |
| DisplayPort version | 1.4a |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Harmonized System (HS) code | 84733080 |
| Processor threads | 4 |
| LAN controller | Intel I226-LM |
| Audio chip | Realtek ALC888S |
| Number of processors supported | 1 |
| ECC supported by processor | No |
| Supported memory types | DDR5-SDRAM |
| ECC | No |
| Non-ECC | Yes |
| Storage drive sizes supported | 2.5; M.2 |
| Supported storage drive types | HDD & SSD |
| Trusted Platform Module (TPM) version | 2.0 |
| BIOS type | UEFI AMI |
| Number of memory slots | 1 |
| Memory slots type | SO-DIMM |
| Serial ports quantity | 2 |
| Memory channels | Single-channel |
| AC adapter output voltage | 19 V |
| Number of power supply units | 1 |
| AC adapter output current | 3.42 A |
| Sustainability compliance | Yes |
| Storage drive interface | Serial ATA III; PCI Express |
| Supported memory clock speeds | 4800 MHz |
| Power cord included | Yes |
| Graphics card family | Intel |
| Storage drives installed | No |
| Compliance certificates | CE; RoHS; Federal Communications Commission (FCC); UKCA; VCCI; BSMI; RCM |
| Internal memory installed | No |
