Elo Touch Solutions 1004L Digital signage flat panel 25.6 cm (10.1") LED 360 cd/m² WXGA Black Touchscreen
479,00 €
Monthly payment from 13.23 €
4178026 E968703
0843173155579
2026-07-29
You are interested in this product?
Create the perfect payment stack with the 10" touchscreen.
Easily pair the 10-inch touchscreen monitor with one of Elo's integrated payment devices - from Elo Pay mobile computers to the Elo Pay 7", the 1004L offers the perfect compact touch display with the connectivity you need at the point of sale.
| Display diagonal | 25.6 cm (10.1") |
| HD type | WXGA |
| Display resolution | 1280 x 800 pixels |
| Screen shape | Flat |
| Native refresh rate | 60 Hz |
| RMS rated power | 4 W |
| Product colour | Black |
| VESA mounting | Yes |
| Panel mounting interface | 75 x 75 mm |
| HDMI ports quantity | 1 |
| Energy efficiency class (SDR) | D |
| Energy consumption (SDR) per 1000 hours | 7 kWh |
| Touchscreen | Yes |
| Display number of colours | 16.7 million colours |
| USB port | Yes |
| USB connector type | USB Type-C; Micro-USB |
| International Protection (IP) code | IP54 |
| Cables included | USB Type-A to USB Type-C; HDMI; Power |
| Package width | 308 mm |
| Package depth | 143 mm |
| Package height | 223 mm |
| Package weight | 2.2 kg |
| Power consumption (off) | 0.25 W |
| Purpose | Universal |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| DC-in jack | Yes |
| Ethernet LAN | No |
| Power consumption (typical) | 6.5 W |
| Built-in speaker(s) | Yes |
| Energy efficiency scale | A to G |
| Mean time between failures (MTBF) | 50000 h |
| Orientation | Horizontal/Vertical |
| Display technology | LED |
| Contrast ratio (typical) | 800:1 |
| Viewing angle, horizontal | 170° |
| Viewing angle, vertical | 170° |
| Display diagonal (metric) | 26 cm |
| On Screen Display (OSD) | Yes |
| Number of OSD languages | 8 |
| On Screen Display (OSD) languages | Simplified Chinese; Traditional Chinese; German; English; Spanish; French; Italian; Japanese |
| Number of built-in speakers | 2 |
| Storage relative humidity (H-H) | 10 - 95% |
| Display brightness | 360 cd/m² |
| Product design | Digital signage flat panel |
| DVI port | No |
| Display width | 249 mm |
| Display depth | 168 mm |
| Display height | 25 mm |
| Display weight | 900 g |
| Panel type | TFT-LCD |
| Response time | 30 ms |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 18 W |
| Touchscreen technology | Projected capacitive system |
| Power consumption (sleep) | 1 W |
| Horizontal scan range | 30 - 80 kHz |
| Number of simultaneous touchpoints | 10 |
| Active display area (W x H) | 216.96 x 135.6 mm |
| Multi-touch | Yes |
| Number of displays | 1 |
