MEAN WELL NDR-120-12 power supply unit 120 W Metallic
69,01 €
Monthly payment from 2.68 €
3894308 NDR-120-12
5902887089886, 1909071064241, 4021087026031, 4260509852777, 5410329626020
Shipping 1-14 b.d.
You are interested in this product?
- Cooling by free air convection
- Installable on DIN rail TS-35/7.5 or 15
- 100% full load burn-in test
- Low cost
Power | |
| Hold time | 16 ms |
| Efficiency | 85.5% |
| Input current | 1.3 A |
| Power protection features | Overload, Over voltage, Overheating, Short circuit |
| AC input voltage | 115 - 230 V |
| AC input frequency | 47 - 63 Hz |
| Total power | 120 W |
Performance | |
| Mean time between failures (MTBF) | 456300 h |
Design | |
| Product colour | Metallic |
Operational conditions | |
| Operating relative humidity (H-H) | 20 - 95% |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 10 - 95% |
Weight & dimensions | |
| Weight | 600 g |
| Width | 40 mm |
| Depth | 113.5 mm |
| Height | 125.2 mm |
Other features | |
| Rise time | 60 ms |
Safety regulation & standards | |
| Safety | Ul508, TUV EN60950-1 approved ;(meet EN60204-1) |
