Dahua Technology Co IP camera cylinder. 8MP STARLIGHT

IP camera cylinder. 8MP STARLIGHT

Short description:

Cylindrical IP camera STARLIGHT WizMind 8 megapixels, 1/1.8" inch Day/Night with IR illumination up to 50m, CMOS sensor, 3840 (H) x 2160 (V); 1~25fps, fixed lens: 3.6mm, viewing angle 87°, H.265/H.264, BLC / HLC, WDR (120dB), ROI, IVS, with built-in microphone; fixed toffee; 3D-DNA: noise reduction technology; microSD 256GB; IP67 moisture resistant; PoE, ePoE, supports ONVIF, CGI standard, model: DH-IPC-HFW5842T-ASE-S2 3.6mm.

Brief technical characteristics:

• 8 megapixel STARLIGHT Day/Night IP camera with IR illumination up to 50m.
• IVS functions: line crossing, perimeter intrusion, image change, disappearing object capture, appearing object capture, face capture.
• 1/1.8" inch 8 Megapixel CMOS sensor.
• 3.6 mm fixed lens M16 (angle of view of the lens about 87°).
• Video compression: H.265, H.265+, H.264, H.264+, H.264B, H.264H, MJPEG.
• Scanning system: Progressive.
• Remote control and live monitoring via Ethernet (WEB): IE8 or later, Chrome, Firefox.
• Free software for camera control (DSS/PSS/SMART PSS), video viewing and archiving via computer network or Internet.
• A free program that allows the user to monitor and view recordings from cameras from different objects, the program allows the image to be saved to the computer.
• The free program for monitoring through a mobile phone or through a handheld computer (DMSS mobile phone surveillance software) is suitable for phones: SYMBIAN, IPHONE, WINDOWS MOBILE, WINDOWS PHONE 8, KINDLE FIRE, BLACKBERY, ANDROID, IPAD, GALAXY TAB, etc..
• The IP camera can be used with software from other companies (VMS Partners): ALNET SYSTEMS, AXXON, DiGiFORT, Exacq Technologies, Genetech, GeoVision, Lenel, milestone, NETvision, NUUO, OnSSI, QNAP, Surveon, UNISIGHT, Aimetis, Cathexis solutions, GEUTEBRUCK, CANON, KSENOS, Kentima Solutions AB, Softguard Tech, Innodep Inc., LuxRiot A&H Software House, Inc., Video Insight, Mirasys Ltd., SEEnergy Corp., Synology, Wavestore and others.
• Number of effective pixels 3840 (H) × 2160 (V).
• Video resolution options available: 3840 × 2160; 3072 × 2048; 3072 × 1728; 2592 × 1944; 2688 × 1520; 2048 × 1536; 2304 × 1296; 1080p (1920 × 1080); 1.3 M (1280 × 960); 720p (1280×720); D1 (704×576/704×480); VGA (640×480); CIF (352×288/352×240).
• Compression rate: main stream: (3840×2160)1~50fps; additional stream: D1(1~25fps); additional third stream: 1080P(1~25fps).
• Bitrate: H.264: 3~20480 Kbps H.265: 3~20480 Kbps.
• Y/N: switches from color operation to black and white at a certain light intensity - mechanical Day/Night function.
• Min. illumination: 0.004Lux / F1.4.
• Fixed aperture (fixed iris).
• 4 pcs. IR LEDs.
• Illumination distance 50m. AND.
• 3D-DNA: noise reduction technology.
• Audio compression: G.711a, G.711Mu, PCM, G.726, G.723.
• Alarm input: 1 channel, 5mA 3-5V DC.
• Alarm output: 1 channel, 300mA 12V DC.
• Audio input: 1 channel RCA.
• Audio output: 1 channel RCA.
• ROI function (4 zones).
• S/N ratio >56dB.
• Electronic Shutter: Auto/Manual, 1/3~1/100000s.
• White light balance: Auto/Manual, HLC / BLC / WDR 120dB.
• 10/100 Mb/s network socket (Ethernet -RJ45).
• Network protocols: IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; ONVIF (Profile S/Profile G/Profile T), CGI, Milestone, P2P.
• Recording: FTP, SFTP, Dahua Cloud or NAS servers.
• Remote control: Monitoring, EPTZ digital zoom, system settings, File download, Preview, software update.
• Unlimited number of users (possibility to grant different rights to each user).
• Maximum user connection at the same time: 20 (traffic 80M).
• Internal memory: micro SD memory port Max 256GB.
• Privacy zones: 8.
• 3-axis mechanism for camera adjustment (can be mounted on the wall and on the ceiling) Pan: 0°~360°; Tilt: 0°~90°; Rotaton: 0~360°.
• Operating temperature: -40°C~+60°C, 95% RH.
• Moisture resistant IP67.
• Power supply: DC12V, PoE (802.3af), ePoE.
• Power consumption: normal 3.9W (12V DC), 4.8W (PoE), maximum 8.2W (12V DC), 9.5W (PoE).
• Dimensions: 244.1 mm × 79 mm × 75.9 mm.
• Weight: 815 g.

Compatible mounts:
PFA130-E.
PFA152-E.
