LevelOne 24V DC Industrial Power Supply, 480W, DIN-Rail,-20 ~ +70 ℃
249,00 €
Monthly payment from 7.31 €
2610160 POW-2462
4015867236581
2026-07-28
You are interested in this product?
DIN-rail Mounting to fit standard DIN-rail mounting systems commonly used in industrial cabinets, allowing for easy installation and space-saving.
It's essential for the power supply to have high energy efficiency, reducing power losses and operating costs while minimizing heat generation.
Power | |
| Hold time | 16 ms |
| Input current | 4.8 A |
| Power protection features | Overload, Over voltage, Short circuit |
| AC input voltage | 90 - 264 V |
| AC input frequency | 47 - 63 Hz |
| Total power | 480 W |
Performance | |
| Mean time between failures (MTBF) | 1041600 h |
Design | |
| Product colour | Blue, Silver |
| Number of fans | 0 fan(s) |
Operational conditions | |
| Operating relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | -20 - 70 °C |
| Storage temperature (T-T) | -40 - 85 °C |
| Storage relative humidity (H-H) | 10 - 95% |
Weight & dimensions | |
| Weight | 1.42 kg |
| Width | 85.5 mm |
| Depth | 128.5 mm |
| Height | 125.2 mm |
Packaging data | |
| Package weight | 1.5 kg |
| Package type | Box |
| Package height | 150 mm |
| Package width | 122 mm |
| Package depth | 171 mm |
Other features | |
| Output voltage note | 24 |
| Voltage tolerance | 1% |
Logistics data | |
| Country of origin | China |
| Master (outer) cases per pallet | 20 pc(s) |
| Master (outer) case width | 266 mm |
| Master (outer) case length | 361 mm |
| Master (outer) case height | 323 mm |
| Master (outer) case gross weight | 11.4 kg |
| Harmonized System (HS) code | 8504403090 |
Safety regulation & standards | |
| Safety | EN 55032 (CISPR32) Class A EN 61000-3-2,-3,EACTPTC020,CNS13438 Class A EN 61000-4-2,3,4,5,6,8,11 EN 61204-3 EN 55035 EN 61000-6-2 (EN 50082-2) |
