Chieftec Task TPS-700S power supply unit 700 W 20+4 pin ATX ATX Black
53,98 €
Monthly payment from 2.29 €
2407701 TPS-700S
0753263076502, 7532630765026
Shipping 2-3 b.d.
You are interested in this product?
The CHIEFTEC Task Series PSU’s are true to their name, and take on any task they are required for without any trouble. With certified 80PLUS Bronze efficiency and all modern protection and safety features, the PSU can be trusted to deliver power efficiently and reliably. With cable lengths extended to 650mm for motherboard and CPU, these power supplies will also serve excellently for builds inside larger cases.
Power | |
| Input current | 10 A |
| Power protection features | Overload, Over voltage, Overheating, Short circuit, Under voltage |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Combined power (+12V) | 648 W |
| Combined power (-12V) | 3.6 W |
| Combined power (+5Vsb) | 12.5 W |
| Max output current (+3.3V) | 19 A |
| Max output current (+12V) | 54 A |
| Max output current (+5V) | 17 A |
| Max output current (+5Vsb) | 2.5 A |
| Max output current (-12V) | 0.3 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 47 - 63 Hz |
| Total power | 700 W |
Performance | |
| Purpose | PC |
| 80 PLUS certification | 80 PLUS Bronze |
| Power supply unit (PSU) form factor | ATX |
| Supported motherboard form factors | ATX |
Design | |
| Product colour | Black |
| Number of fans | 1 fan(s) |
| Fan diameter | 12 cm |
Ports & interfaces | |
| Number of SATA power connectors | 6 |
| Peripheral (Molex) power connectors (4-pin) | 3 |
| ATX power connector (20+4 pin) | Yes |
| PCI Express power connectors (6+2 pin) | 2 |
| Motherboard power connector | 20+4 pin ATX |
| Cabling type | Non-Modular |
| Motherboard power cable length | 65 cm |
| SATA power cable length | 500, 150 |
| Peripheral (Molex) power cable length | 150, 500 |
| PCI Express power cable length | 50 cm |
| EPS power connector (4+4 pin) | Yes |
Weight & dimensions | |
| Weight | 1.74 kg |
| Width | 150 mm |
| Depth | 140 mm |
| Height | 87 mm |
Packaging data | |
| Package weight | 2.15 kg |
| Package type | Box |
Other features | |
| EPS cable length | 65 cm |
Logistics data | |
| Harmonized System (HS) code | 84733020 |
Certificates | |
| Certification | ErP, CE, CB, EAC, TUV |
| Compliance certificates | RoHS |
