Equip DisplayPort 1.4 Active Optical Cable, 20m, 8K/60Hz
139,00 €
Monthly payment from 4.48 €
2231243 119442
4015867223055
2026-07-28
You are interested in this product?
The equip 119442 DisplayPort 1.4 Active Optical Cable (AOC) is a high-performance cable used for transmitting digital video signals over long distances. Unlike copper cables, which have limitations on how far they can transmit signals without signal degradation, DisplayPort 1.4 AOC can transmit data up to 100 meters without the need for additional signal boosters or repeaters.
The cable is designed to support the DisplayPort 1.4 standard, which offers high bandwidth and supports resolutions up to 8K at 60Hz or 4K at 120Hz. DisplayPort 1.4 AOC also supports High Dynamic Range (HDR) and Display Stream Compression (DSC), which allows for even higher resolutions and refresh rates.
The active component of the cable is a microchip embedded in the connector that converts the electrical signals to optical signals, which are then transmitted over the optical fiber. The cable is also immune to electromagnetic interference (EMI) and radio frequency interference (RFI), making it ideal for use in environments with high levels of electromagnetic interference.
| Product colour | Black |
| High Dynamic Range (HDR) supported | Yes |
| Maximum refresh rate | 120 Hz |
| Weight | 510 g |
| Cable length | 20 m |
| Connector 1 | DisplayPort |
| Connector 2 | DisplayPort |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector contacts plating | Gold |
| Quantity per pack | 1 pc(s) |
| Package type | Box |
| Package width | 205 mm |
| Package depth | 65 mm |
| Package height | 205 mm |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum resolution | 7680 x 4320 pixels |
| Package weight | 700 g |
| Master (outer) case width | 300 mm |
| Master (outer) case length | 230 mm |
| Master (outer) case height | 460 mm |
| Master (outer) case gross weight | 7 kg |
| Products per master (outer) case | 10 pc(s) |
| Country of origin | China |
| Supported graphics resolutions | 1920 x 1200 (WUXGA); 2560 x 1440; 3840 x 2160; 5120 x 2880; 7680 x 4320 |
| HDCP | Yes |
| DisplayPort version | 1.4 |
| HDCP version | 2.2 |
| Sustainability compliance | Yes |
| Bandwidth | 32400 MB/s |
| Multi-Stream Transport (MST) | Yes |
| Display Stream Compression (DSC) | Yes |
| Compliance certificates | CE; RoHS |
