Alpenföhn Brocken 4 Max Processor Air cooler 12 cm Black 1 pc(s)
109,00 €
Monthly payment from 3.71 €
2189541 84000000211
4250280312751
2026-07-28
You are interested in this product?
Matt black surface coating, 6x6mm heatpipes, large asymmetric heatsink and an aerodynamically optimised fin design - Brocken 4 Max combines pure performance with almost silent
operation even in demanding systems.
JetStream fans
Our brand new JetStream fans set new standards in our Alpenföhn portfolio! Each fan has an airflow-optimised impeller, a modified frame and next-gen bearings, which ensure excellent running smoothness during maximum performance. The JetStreams anti vibration pads reduce vibrations to a minimum.
High-end heat pipes & copper baseplate
The 6 high-end heat pipes are connected to the nickel-plated copper base plate over a large area, which ensures that the heat from the CPU is effectively absorbed. This enables the heat pipes to transport the heat of the processor quickly and efficiently to the large-area heat sink.
Matt black surface coating
The entire heatsink of the Brocken 4 is coated in classy matt black. Black is beautiful – do you agree?
Asymmetrical heat sink
The asymmetrical design of the Brocken 4 Max gives you maximised flexibility in the selection of RAM modules. No matter how high the heat spreader of the module may be - it fits without any problems! 100% RAM compatibility on sockets 1700, 1200, 115X, AM5 and AM4.
Compatibility
The included Rock Mount 3 mounting system offers a secure connection to the sockets: Intel® LGA: 1700, 1200, 115X, 20XX AMD: AM5, AM4
Expandable fan assembly
For even more performance, the scope of delivery includes additional fan clamps and decoupling elements. This means you can easily add an additional 120 mm fan to the other side of the heatsink and increase the cooling performance even more.
Performance | |
| Supported processor sockets | LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), Socket AM4, LGA 2011-v3 (Socket R), LGA 2066, LGA 1200 (Socket H5), LGA 2011 (Socket R), LGA 1700 |
| Type | Air cooler |
| Fan diameter | 12 cm |
| Airflow | 94 m³/h |
| Maximum air pressure | 1.74 mmH2O |
| Pulse-width modulation (PWM) support | Yes |
| Quantity per pack | 1 pc(s) |
| Fan 2 rotational speed (min) | 400 RPM |
| Fan 2 rotational speed (max) | 1800 RPM |
| Fan 2 noise level (high speed) | 24.7 dB |
| Fan 2 maximum air pressure | 1.2 mmH2O |
| Fan speed (min) | 400 RPM |
| Fan speed (max) | 1600 RPM |
| Fan noise level (max) | 22.8 dB |
| Fan bearing technology | Hydraulic bearing |
| Suitable location | Processor |
Design | |
| Product colour | Black |
| Number of fans | 2 fan(s) |
| Number of heat pipes | 6 |
| Fan connector | 4-pin |
| Fins material | Aluminium |
| Number of fan blades | 9 |
| Radiator material | Aluminum |
| Base plate material | Copper |
Power | |
| Rated current | 0.15 A |
| Thermal Design Power (TDP) | 250 W |
| Fan voltage | 12 V |
| Fan power consumption | 1.8 W |
Weight & dimensions | |
| Weight | 1.26 kg |
| Height | 158 mm |
| Width | 127 mm |
| Depth | 129 mm |
| Heat pipes diameter | 6 mm |
| Fan dimensions (W x D x H) | 120 x 120 x 27 mm |
| Fan 2 dimensions (W x D x H) | 120 x 120 x 16 mm |
Packaging content | |
| Screws included | Yes |
| Package type | Box |
| Mounting kit | Yes |
| Installation instruction | Yes |
| CPU bracket(s) | Yes |
Other features | |
| Fan rated voltage | 5 - 13.2 V |
