Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

The product's shade and actual color may differ from what is shown in the picture, as the images are for illustrative purposes. The product description is general and may not include all the product's features.

Axis 01633-001 network switch Managed Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black

1 087,00 €
Monthly payment from 28.89 €
2100562

01633-001

7331021066199

Shipping 2-3 b.d.

Quantity

You are interested in this product?
(Read terms of service)
AXIS T8504-R Industrial PoE Switch is a 4-port managed industrial PoE Gigabit switch. In addition, the switch is equipped with two RJ45 and two SFP data ports that allows for extra devices to be connected. The switch uses the same intuitive administrator interface as AXIS T85 PoE Network Switch Series. The ruggedized switch is perfect for challenging environments when mounted inside a surveillance cabinet. It is designed to withstand shock, vibrations and temperatures from -40 °C to 75 °C (-40 °F to 167 °F), making it perfect for high demanding installations such as alongside highways and tunnels.
Network
Networking standards IEEE 802.1x, IEEE 802.1Q
Jumbo frames support Yes
Jumbo frames 9216
Ports & interfaces
Fiber optic connector SFP
Security
Security algorithms HTTPS, SNMP, SNMPv3
MAC address table 8000 entries
Design
Product colour Black
Housing material Aluminium
Power
Power over Ethernet (PoE) Yes
Operational conditions
Operating temperature (T-T) -40 - 75 °C
Storage temperature (T-T) -40 - 85 °C
Operating relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 62 mm
Depth 130 mm
Height 135 mm
Weight 600 g
Certificates
Certification EN 55032, EN 55024, FCC, ICES-003, VCCI, RCM AS/NZS CISPR 32, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4 IEC 62236-4, IEC/EN/UL 60950-1, IEC 60068-2-6, IEC 60068-2-27, 60068-2-31, NEMA TS-2-2003
Logistics data
Harmonized System (HS) code 85176990
Packaging content
Quick start guide Yes
