BUFFER PULSE POWER ADAPTER AUPS-70-120-F ATTE
149.00 €
Ikm. maksa no 4,74 €
3672360 AUPS-70-120-F
5902143690955
Piegāde 11-15 d.d.
Šī prece Jūs ieinteresēja
Viss par produktu
The buffer power supply is designed to power alarm control panels, sensors, code locks, cameras, manipulators, intercoms and other devices that are part of the alarm system.
It is necessary to pay special attention to proper cooling of the power supply during operation!
| Power supply type : | Transformer |
| Input voltage : | 190 ... 260 V AC / 50 Hz |
| Output voltage : | 10.2 ... 13.8 V DC (buffer operation) |
| Maximum output current (total) : | 6 A (continuous operation) |
| Battery charging current : | 1 A / 2 A - Shorter on JP1 |
| Power : | 72 W (continuous operation) |
| Number of outputs : | 1 |
| Main features : | LED indication Efficiency : 90% @ 70 W OC type technical outputs signaling about voltage loss at the power supply output (OUF) and voltage loss in the 230V network (ACF) Main cable entries at the back of the housing Module raster assembly system (compatible with ATTE brand devices) - 10.8 mm raster Wall mounting For indoor use Sealing class : IP20 |
| Protective measures : | From short circuit From overloads From overvoltages Overheating Anti-sabotage Reverse connection From excessive discharge From overload |
| Adapter operation control : | AC mains power presence signaling DC output voltage presence signaling Battery charging signaling (internal) |
| Battery compartment : | 12V / 7 ... 18Ah |
| Max. Battery Dimensions : | 220 x 170 x 100 mm |
| Working temperature : | -25 ... 50 °C |
| Weight : | 2.3 kg |
| Dimensions : | 325 x 305 x 88 mm |
| Manufacturer / Brand : | ATTE |
| Warranty : | 3 years |
