Produkta tonis un faktiskā krāsa var atšķirties no attēlā redzamā, jo attēli ir ilustratīvi. Produkta apraksts ir vispārīgs un, iespējams, tajā nav iekļautas visas produkta īpašības.

Hub Buffer set for 16 IP switch cameras 16P+2G each ATTE IPUPS-16-20-H

594.34 €
Ikm. maksa no 16,20 €
3657060

21314

5902143690375

Piegāde 7-9 d.d.

Šī prece Jūs ieinteresēja
(Lasīt pakalpojumu sniegšanas noteikumus)

Viss par produktu

LAN ports :
  • 2 x RJ45 10/100/1000 Base-T - Uplink
  • 16 x RJ45 10/100 Base-T , PoE 802.3af/at / Passive PoE
    • Management :
    LED diodes : 2 x 230V AC IN, 2 x 12V DC OUT, 2 x 48V DC OUT, 2 x CHARGING (battery charging), 20 x LAN, 4 x Gigabit Ethernet
    Transmission speed :
  • 10 / 100 / 1000 Mbps : 2 x Uplink port
  • 10 / 100 Mbps: 16 x LAN & PoE ports
    • Maximum output power :
  • 40 W @ Passive PoE - LAN & PoE ports,
  • 30 W @ PoE (802.3af/at) - LAN & PoE ports
    • Maximum total power : 130W
    Main features :
  • Independent on/off PoE power capability for each port LAN 1 ... LAN 8
  • Modular design simplifies maintenance tasks and allows for quick and easy system expansion
  • The raster module assembly system makes it easy to expand the device with subsequent modules
  • 2 x Battery compartment: 12 V / 18 Ah
  • Battery charging current: 1 A / 2 A - (set by switch JP1)
  • OC type technical outputs signaling about voltage loss at the power supply output (OUF) and voltage loss in the 230V network (ACF)
  • Protection against deep battery discharge
  • Power supply thermal protection: 130 °C
  • TAMPER switch signaling the opening of the enclosure
    • Power supply : 230V AC
    Weight : 4.7 kg
    Dimensions : 455 x 405 x 150 mm
    Manufacturer / Brand : ATTE
    Warranty : 2 years
