SATEL VADU UNIVERSĀLAIS DETEKTORS XD-2L BR (BRUNS)
40.15 €
Ikm. maksa no 1,93 €
2991747 37861
5905033338524
Piegāde 8-12 d.d.
Šī prece Jūs ieinteresēja
Viss par produktu
The sensor with cable XD-2L-BR can work in one of 4 modes, which makes it an extremely versatile device.
Depending on the needs, the device can be configured as: a magnetic sensor, a vibration sensor, a shock sensor with a contactor, or a water inundation sensor (requires an external probe FPX-1 - available separately).
XD-2L-BR works with any alarm center.
| Support : | Alarm center |
| Detection : | Door or window opening, Vibration, Water |
| Environmental class EN 50130-5 : | II |
| Degree of protection (Grade) : | 2 |
| Sensitivity adjustment : | Shock sensor |
| Alarm : | LED diode, Signal to the alarm center |
| Permissible load (resistive) of relay contacts : | 40 mA / 24 V DC |
| Meals : | 12 V DC / 15 mA (max) |
| Main features : | Working mode: Magnetic sensor - Opening a door or window - Maximum distance between detector and magnet : 15 mm (surface magnet), 19 mm (recessed magnet) - input, thanks to which it is possible to connect a wireless, NC-type sensor - 1 Alarm output Shock sensor - Detection of overcoming shocks and vibrations in windows and doors when force is applied - Distance: 3 m - input, thanks to which it is possible to connect a wireless, NC-type sensor - 1 Alarm output Magnetic and shock sensor - Detection of overcoming shocks and vibrations in windows and doors when force is applied - Opening a door or window - input, thanks to which it is possible to connect a wireless, NC-type sensor - 1/2 Alarm outputs Water inundation sensor - Probe FPX-1 available separately if required - sensing the presence of water in rooms at risk of flooding - 1 Alarm output Alarm output: 2EOL/NC, NC Built-in parameter resistors 2EOL: 2 x 1.1kΩ, 2 x 2.2 kΩ, 2 x 4.7 kΩ, 2 x 5.6 kΩ, 2 x 6.8 kΩ LED indication - Remote configuration Supply voltage monitoring Tamper detection - case opening Includes 2 magnets (for surface mounting and flush mounting) Complies with standards EN 50130-4, EN 50130-5, EN 50131-1, EN 50131-2-6 |
| Color : | Brown |
| Working temperature : | -10 °C ... 55 °C |
| Weight : | 0.04 kg (sensor) |
| Dimensions : | 25 x 136 x 29 mm (sensor) 15 x 52 x 6 / 8 / 10 / 12 / 14 mm (surface magnet) Ø 10 x 28 mm (recessed magnet) |
| Manufacturer / Brand : | SATEL |
| Warranty : | 2 years |
