Genius G-Bat 300 komplekts 6m divvērtņu vārtiem
2793478 22634
8055195065435
Piegāde 8-12 d.d.
Viss par produktu
The drive GENIUS-GBAT-300/KIT is intended for swing gates, where the length of one frame is 3 m.
Thanks to many technological improvements, the device is safe and convenient to use.
There is no need to install locks in the drive (self-locking).
For example, in the event of a power failure, a simple gearbox mechanism in the drive allows the door to be operated manually.
W zątewie znało się: 2 actuators (cylinders) - model G-Bat 300, controller Brain 592, photocell set VEGA (transmitter + receiver pair), radio communication module 433 RC, radio remote control ECHO TX4 controller housing - model JA320 and necessary mounting accessories.
| Gate drive type : | Mechanical, For swing gates - a set of double-door gates |
| Maximum pulling force : | 3500 N |
| Engine type : | Single phase, 230 V AC |
| Maximum gate length : | 3 m (single wing with electromagnetic lock option) |
| Linear speed : | 16 mm/s (max) |
| Rotation angle : | 110° (max) |
| Automatic gate closing : | ✔ |
| Automatic gear lock : | ✔ |
| Limit Switch : | ✔ |
| It is possible to connect a photocell : | ✔ |
| A signal lamp can be connected : | ✔ |
| Maximum number of programmed pilots : | 255 Channels |
| Wireless transmission distance : | ≥ 50 m (in open space) |
| Frequency band working systems : | 433.92 MHz |
| Number of cycles per hour : | ≤ 30 |
| Main features : | Self-braking gear The set includes mounting brackets: rear bracket (for strut) to be welded and/or bolted front bracket (to sash) for welding The controller body is included |
| Meals : | 220 ... 240 V AC , 50 / 60 Hz |
| Body : | Plastic + Metal (drives G-Bat 300) Plastic (controller body) |
| Sealing class : | IP44 (drives G-Bat 300) IP55 (controller housing) |
| Color : | Black (drives G-Bat 300) Light gray (controller housing) |
| Working temperature : | -20 °C ... 55 °C |
| Weight : | 5.6 kg (single gate drive) |
| Dimensions : | 640 x 107 x 185 mm (single gate drive) 265 x 205 x 87 mm (controller body) |
| Manufacturer / Brand : | GENIUS |
| Warranty : | 2 years |
