HN-B25/3 MINIATŪRAS Strāvas slēdzis B 25A 3P 3M 6KA
23,89 €
22.89 €
2702409 194883
9010238063679
Piegāde 8-12 d.d.
Šī prece Jūs ieinteresēja
Viss par produktu
Actuator switch with type B description and rated current 25A.
The HN-B25/3 switch is intended for mounting on a DIN TS-35 rail.
Circuit breakers with characteristic B are designed to protect lighting circuits, controls and sockets from short circuits and overloads.
| Device Type : | Actuator switch, Three-phase |
| Nominal current : | 25 A |
| Number of poles : | 3 |
| Launch description : | Type B |
| Rated short-circuit duration : | 6000 A |
| Nominal voltage : | 230 V AC / 50 Hz 400 V AC / 50 Hz |
| Type of connectors : | threaded terminals |
| Wire cross-section : | 1 mm² - 25 mm² |
| Main features : | Contact position indicator Possibility of sealing |
| Body : | Plastic, mounting on DIN, TS-35 rail |
| Width in modules 17.5 mm : | 3 |
| Weight : | 0.316 kg |
| Dimensions : | 52.5 x 84.5 x 73 mm |
| Manufacturer / Brand : | EATON |
| Warranty : | 2 years |
