IPS 600 DUO sprieguma pārveidotājs 12/24V/230V
2525713 3IPS912246
5903111886165
Piegāde 8-12 d.d.
Viss par produktu
The Volt IPS-600 Duo inverter allows you to power devices that require 230V alternating current from batteries and car devices with a direct voltage of 12V or 24V. At the output, the converter produces a modified sine wave, that is, an alternating voltage with a square wave. The rms value of the waveform is identical to the rms value of the sine waveform in the electrical network. The inverter has many protections such as: short circuit, thermal, under voltage, over voltage and overload protection. The efficiency of the Volt IPS 600 Duo inverter is 92%.
Technical data:
- Battery voltage: 12 V or 24 V
- Input voltage: 10.5 V to 31 V DC
- Output voltage: 225 V to 235 V AC
- Overload power (instantaneous): 600 W
- Rated power (continuous): 300 W
- Output voltage frequency: 50 Hz (+/- 2 Hz)
- Efficiency at full load: 92%
- Voltage Protection Threshold: 10.7V (0.3V)
- Operating temperature: -10°C to 40°C
- USB socket: yes - 5V
