Hismart HDMI Cable Tester NF622
32.98 €
2495350 NF622
9990000912285
Piegāde 1-2 d.d.
Šī prece Jūs ieinteresēja
Viss par produktu
HDMI cable tester NF622.Features:
Quick and accurate inspection using A - A, A - C, CA and C - C connectors.
Check the HDMI cables for malfunctions, short, open and crossover.
Map continuity and proper configuration.
19pin and ground connectors, 4 status lights.
Can only check the wiring diagram with the main unit.
Adjustable test modes: fast/slow scan/manual test/step by step.
Technical data:
Cable versions supported: HDMI cables with Type A and Type C connectors, supporting 1.0, 1.1, 1.2, 1.2a, 1.3, 1.3a, 1.3b, 1.3c, 1.4, 1.4a, Category 1 and Category 2 HDMI cables.
Support Test: To detect 19 pin wiring diagram and shielding.
Main device test interface: HDMI (Type A) x 2, Mini HDMI (Type C) x1.
Remote device test interface: HDMI (Type A) x 2, Mini HDMI (Type C) x1.
Test type: main unit/ mater and remote unit
Test mode: fast / slow scan / step by step
Test distance: less than 50 meters.
Display: 19 light and panel diodes on main and remote unit.
Beep indication.
Low battery indicator: 6.0 V.
Power supply: DC 9V (NEAD 1604 / 6F22) x 1 (not included).
Storage: -10C to 55C <70% RH.
Dimensions: 103x66x27mm.
Warranty: 24 months
