TIME RELAY MODULE OR-PRE-452/UNI ORNO
59.00 €
Ikm. maksa no 2,42 €
2473197 OR-PRE-452/UNI
5904988904938
Šī prece nav vairs pieejama
Šī prece Jūs ieinteresēja
Viss par produktu
The time switch OR-PRE-452/UNI provides power to the equipment at a time set by the user.
Turning on the supply voltage causes the relay to immediately turn on for the set time. After the set time has elapsed, the relay turns off.
| Number of relay outputs : | 1 |
| Feed : | 12 ... 230 V AC / DC |
| Rated power consumption : | ≤ 1.5 W (max) |
| Maximum contact load : | 16 A 250 V AC 16 A 24 V DC |
| Output : | 1 x NO/NC |
| Main features : | Smooth switch-on time adjustment Time adjustment range: 1 s / 10 s / 1 m / 10 m / 1 h / 10 h / 1 day / 10 days LED indication mounting on DIN, TS-35 rail |
| Working temperature : | -20 °C ... 50 °C |
| Weight : | 0.064 kg |
| Dimensions : | 90 x 17 x 65 mm |
| Manufacturer / Brand : | ORN |
| Warranty : | 2 years |
