TP-Link 300Mbps Wireless N Access Point
23,68 €
4528313 TL-WA801ND V1
6935364051419, 0014444453865, 0115970741669, 0151902933474, 0521621394960, 0693536405144, 0722550156821, 0746320533650, 0807030505884, 4050196362815, 5052916517535, 5054484152927, 8459730514196
Shipping 4-6 b.d.
You are interested in this product?
The TP-LINK Wireless N Access Point TL-WA801ND is designed to establish or expand a scalable high-speed wireless N network or to connect multiple Ethernet enabled devices such as game consoles, digital media adapters, printers, or network attached storage devices to a wireless network. The APs support a host of different functions that makes your wireless networking experience more flexible than ever before. Now, you can enjoy a better Internet experience when downloading, gaming, video streaming or with any other application that you may wish to use.
Wireless N - Speed & Range
Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, it simultaneously works through two antennas to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!
Multiple Operating Modes
- Easy to Build WLAN
Supports multiple operation modes (Access Point, Multi-SSID, Client, Repeater, Bridge with AP) to enable various wireless applications to give users a more dynamic and comprehensive experience when using their AP. Multiple operating mode also helps you easily to build wireless network for hard-to-wire locations or eliminating wireless dead zone.
Passive PoE Supported
- More Flexible Deployment
The TL-WA801ND is able to be powered using an Ethernet cable to simultaneously send data and electricity to wherever your AP may be located even up to 100 feet away. This feature multiplies your options allowing you to place the AP in a position that is most convenient to get the best signal possible, such as on the wall or on the ceiling of your office.
Wireless LAN features | |
| Modulation | 16-QAM, 64-QAM, CCK, DBPSK, DQPSK, OFDM |
Network | |
| Networking standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Ethernet LAN data rates | 10, 100 |
| Receiver sensitivity | 270M: -68dBm@10% PER, 130M: -68dBm@10% PER, 108M: -68dBm@10% PER, 54M: -68dBm@10% PER, 11M: -85dBm@8% PER, 6M: -88dBm@10% PER, 1M: -90dBm@8% PER |
| Cabling technology | 10/100Base-T(X) |
Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
Management features | |
| Reset button | Yes |
| Quality of Service (QoS) support | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
Security | |
| Security algorithms | WPA, WPA-PSK, WPA2, WPA2-PSK, WPS, 64-bit WEP, 128-bit WEP, SSID, 152-bit WEP |
| MAC address filtering | Yes |
Protocols | |
| Management protocols | SNMP |
Design | |
| LED indicators | Yes |
Antenna | |
| Antenna connector type | RP-SMA |
| Antenna gain level (max) | 5 dBi |
| Antennas quantity | 2 |
| Antenna direction type | Omni-directional |
| Antenna type | External |
Power | |
| Output voltage | 9 V |
| Output current | 0.6 A |
| Power over Ethernet (PoE) | Yes |
Operational conditions | |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
Weight & dimensions | |
| Width | 181 mm |
| Depth | 125 mm |
| Height | 36 mm |
Packaging data | |
| Package width | 310 mm |
| Package depth | 223 mm |
| Package height | 70 mm |
| Package weight | 600 g |
Other features | |
| Compatible operating systems | Linux, Windows 98SE, NT, 2000, XP, Vista, 7, MAC OS, NetWare, UNIX |
| Output power description | 9VDC / 0.85A |
| Frequency band | 2.4 - 2.4835 GHz |
| Maximum data transfer rate | 300 Mbit/s |
Certificates | |
| Certification | CE, FCC, RoHS |
Packaging content | |
| AC adapter included | Yes |
