Televes 149921 television antenna Outdoor Dual 17 dB
89,22 €
Monthly payment from 3.20 €
640805 149921
8424450185056
Goods will arrive at the Tallinn warehouse on 10.07.26
You are interested in this product?
Intelligent antenna including the BOSSTech system, designed for quality reception of UHF (DTT), optimizing LTE band rejection up to channel 48 (694MHz).
TForce technology:
Televes transitions from the traditional silicon era into a new era of electronic component design, allowing integrated circuits to be precisely manufactured for microwave frequency bands. Utilizing “State of the Art” MMIC technology TForce is manufactured using semiconductor compounds such as gallium arsenide (GaAs), providing the resulting products with unparalleled features and performance
Televes has reinvented the antenna concept. Until now, an antenna was just the reception component of a TV installation in which gain and directivity were the main features. The introduction of a smart device like BOSS provides the antenna with the capacity to receive very weak signals without the risk of being affected by very strong signals, the result is a dynamic balance between weak and strong signals that provides optimum signal levels at all times: the "dynamic range" concept turns out to be the most outstanding among quality parameters.
The creation of TForce with BOSS technology using MMIC components is an extraordinary milestone in the optimization of the dynamic range. The technology that allowed the reception of lost signals from distant satellites is now allowing the enhancement of the coverage range in DTT installations.
Features | |
| Supported radio bands | UHF |
| Antenna type | Dual |
| Channels quantity | 48 channels |
| Product colour | Orange |
| Antenna gain level (max) | 42 dBi |
| Horizontal beam width | 30° |
| Front to back ratio | 20 dB |
| Wind load | 165 |
| Quantity per box | 1 pc(s) |
| Gain | 17 dB |
| Number of elements | 1 |
| Material | Aluminium, ABS |
| Placement | Outdoor |
| Wall mountable | Yes |
| Frequency range | 470 - 694 MHz |
| Windproof | Yes |
| Survival wind speed | 150 km/h |
| Polarization | Vertical polarization |
| Telescopic | No |
Weight & dimensions | |
| Weight | 2.09 kg |
| Depth | 560 mm |
| Height | 736 mm |
| Width | 1142 mm |
Packaging data | |
| Package type | Trapped blister |
| Quantity per pack | 1 pc(s) |
Power | |
| Power source type | DC |
| DC input voltage | 12 - 24 V |
