Mikrotik Chateau 5G R17 ax wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black, Grey
341,14 €
Monthly payment from 9.68 €
3822961 S53UG+5HAXD2HAXD-TC&RG650E-EU
4752224009852
Shipping 3-7 b.d.
You are interested in this product?
Now powered by 5G Release 17 cutting-edge modem, Chateau takes full advantage of the latest mobile technologies, including advanced carrier aggregation combinations. That means faster downlink speeds, increased signal stability and responsiveness, even in regions where the mobile tower is far away. Wherever you are, Chateau finds the signal sweet spot.
Your network, your rules: eSIM or microSIM
Chateau has a true embedded SIM (eSIM) built right in, fully compatible with:
- MikroTik Connectivity (pre-activated data plans)
- Third-party eSIMs (Mobile operator eSIM profiles)
- Multiple eSIM profiles (easily added, switched, or stored)
With four powerful built-in LTE/5G antennas and two external dual-chain Wi-Fi 6 antennas, Chateau gives you great performance for download and upload even in a busy, crowded environment:
- Smart aggregation with wide regional FDD + TDD band support;
- Extra strong signal pickup thanks to 4x4 MIMO;
- Wi-Fi coverage designed for homes of all sizes, including multi-floor setups.
Chateau runs RouterOS v7, MikroTik’s industrial-grade operating system used by ISPs and sysadmins around the world – but with a simple user-friendly interface that anyone can learn to use. And if you’re not sure about diving deep into the world of networking – no worries, we also have iOS/Android app for even easier installation!
Set up a secure VPN. Optimize streaming. Limit bandwidth. Create VLANs. Block sites. Send SMS alerts when usage peaks. All without subscriptions or paywalls.
WAN connection | |
| SIM card slot | Yes |
Wireless LAN features | |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
| WLAN data transfer rate (max) | 1200 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 1200 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Wi-Fi standards | 802.11a, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
Network | |
| Ethernet LAN | Yes |
| Ethernet LAN data rates | 10, 100, 1000 |
| Ethernet LAN interface type | Gigabit Ethernet |
Mobile network | |
| 4G bands supported | 700, 850, 1800, 2100, 2500, 2600, 900, 2300, 800, 1500, 3500, 3700 |
| 4G standard | LTE-TDD & LTE-FDD |
| SIM card type | MicroSIM |
| Mobile network generation | 5G |
| 5G standard | Sub6 NSA, Sub6 SA |
| 5G bands supported | 700, 850, 1800, 2100, 2600, 3500, 800, 900, 2300, 3700, 2500, 1500 |
| 3G bands supported | 850, 900, 2100 |
Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 5 |
| DC-in jack | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB port | Yes |
Design | |
| Product colour | Black, Grey |
| Indication light | Yes |
| Product type | Desktop/pole router |
| International Protection (IP) code | IP20 |
Antenna | |
| Antenna design | Internal |
Features | |
| Built-in processor | Yes |
| Processor cores | 4 |
| Internal memory | 1000 MB |
| Flash memory | 128 MB |
Power | |
| Power source type | DC |
| Power consumption (typical) | 27 W |
Operational conditions | |
| Operating temperature (T-T) | -40 - 70 °C |
Certificates | |
| Certification | CE, EAC, ROHS |
Logistics data | |
| Quantity per pack | 1 pc(s) |
Packaging content | |
| Cables included | Power, UTP |
