RELAY MODULE ESP12-2R-D8 Wi-Fi
29,00 €
2397103 ESP12-2R-D8
5902887067280
Piegāde 1-14 d.d.
Šī prece Jūs ieinteresēja
The ESP12-2R-D8 module provides the possibility of wireless control with 2 transmitters.
Communication with the device is possible with the help of the Wi-Fi interface.
The package tools Arduino IDE or Eclipse can be used for programming the module.
Programming of the module takes place thanks to the serial UART TTL port.
| Management : | Wi-Fi |
| Protocol : | IEEE 802.11 b/g/n/e/i, Wi-Fi Direct (P2P), TCP, UDP |
| Number of inputs : | - |
| Number of relay outputs : | 2 pcs. |
| Maximum contact load : | 10 A / 250 V AC , 10 A / 30 V DC |
| Output : | 2 x NO/NC |
| Main features : | LED indication Programming using Arduino IDE or Eclipse tools The module can be used as a system element in IoT (Internet of Things) The Wi-Fi module works in the 2.4 GHz band |
| Feed : | 7 V ... 30 V DC or 5 V DC (power supply not included) |
| Weight : | 0.04 kg |
| Dimensions : | 78 x 47 x 19 mm |
| Warranty : | 2 years |
