2. KLASES SLĒGTA REŽĪMA BUFERA BAROŠANAS APGĀDE Pulsar AWZG2-12V2A-B
79,37 €
Ikm. maksa no 2.94 €
3171996 28039
5902135319642
Piegāde 2026-07-22 Latvijas teritorijā +1 diena
Šī prece Jūs ieinteresēja
The buffer power supply is designed to power alarm control panels, sensors, code locks, cameras, manipulators, telephone locks and other devices that are part of the alarm system.
It is necessary to pay special attention to the proper cooling of the power supply during work!.
Attention!
The dimensions of the housing do not allow the installation of 12 Ah and 14 Ah batteries.
| Power supply type : | Transformer |
| Input voltage : | 230 V AC |
| Output voltage : | 11.0 V ... 13.8 V (buffer operation) |
| Maximum output current (total) : | 2 A |
| Battery charging current : | 0.2 A / 0.5 A (set by switch JP1) |
| Power : | 27 W |
| Number of outputs : | 1 |
| Protective measures : | From short circuit From overloads From overvoltages Overheating Anti-sabotage Reverse connection From overdischarges |
| Adapter operation control : | Signaling the presence of power from the network AC Signaling the presence of the output voltage DC No battery or it is damaged Battery charging - on the main board EPS FLT input - signals an AC power failure APS FLT output - Battery failure signaling |
| Main features : | Output voltage - stabilized Automation microprocessor system Battery power supply and maintenance control. Tamper signaling - NC LED indication 2 x OC output Complies with standard EN 50131-6:2017 @ Grade 2 Complies with standard EN 60839-11-2:2015+AC:2015 @ Grade 2 |
| Space for the battery : | 12 V / 9 Ah (max) |
| Max. Battery dimensions : | 190 x 100 x 75 mm |
| Weight : | 2.02 kg |
| Dimensions : | 205 x 237 x 90 mm |
| Manufacturer / Brand : | PULSAR |
| Warranty : | 5 years |
