Cyclo C720 komplekts - FAAC 24V līdz 400kg bīdāmie vārti
2470703 8659
8055195064704
Piegāde 1-14 d.d.
The electromechanical drive FAAC-CYCLO-24V-C720/KIT is designed to cooperate with sliding gates whose weight does not exceed 400 kg.
Thanks to many technological improvements, the device is safe and convenient to use.
Due to the built-in overload protection, when the gate collides with an obstacle during closing, the drive will stop immediately and then open the gate.
The automatic closing function allows you to set the time of full opening, after which the gate will close automatically.
In addition, the actuator automatically locks when the drive is complete, preventing manual opening of the gate.
For this reason, there is no need to use additional devices to protect the gate from opening.
In the event of an emergency or power failure, the lock can be released manually using a key.
The kit includes: drive - model C720 with built-in controller E721, drive - model 391, 2 hinged frames, photocell set XP20BD. (transmitter and receiver pair), radio communication module XF868, radio remote control XT4, a set of 2 emergency, 2 limit switches and necessary installation accessories..
| Gate drive type : | Mechanical, for sliding gates - Starter kit |
| Torque : | 18 Nm (max) |
| Maximum pulling force : | 320 N |
| Engine type : | Brushed motor, 24 V DC |
| Maximum gate weight : | 400 kg |
| Maximum gate length : | 15 years |
| Linear speed : | 18 m/min (max) |
| Automatic gate closing : | ✔ |
| Automatic gear lock : | ✔ |
| Limit Switch : | ✔ |
| It is possible to connect a photocell : | ✔ |
| A signal lamp can be connected : | ✔ |
| Maximum number of programmed pilots : | 250 Channels |
| Wireless transmission distance : | ≥ 50 m (in open space) |
| Frequency band working systems : | 868.35 MHz |
| Main features : | Can be combined with emergency battery XBAT 24 Master-Slave function for connecting two drives using anti-copper gates |
| Meals : | 230 V AC / 50 Hz |
| Body : | Plastic |
| Sealing class : | IP44 |
| Color : | Gray |
| Working temperature : | -20 °C ... 55 °C |
| Weight : | 6.11 kg |
| Dimensions : | 304 x 282 x 180 mm |
| Manufacturer / Brand : | FAAC |
| Warranty : | 2 years |
