TRANSMITTER OR-PI-456/24UC ORNO
49,00 €
Kuumakse alates 2.16 €
2482490 OR-PI-456/24UC
5904988904983
Tarneaeg 1-14 t.p.
Kauba vastu huvi?
Allows to increase the maximum load capacity of transistor outputs and provides galvanic isolation between the output line and the load.
| Number of relay outputs : | 1 |
| Feed : | 24V DC / AC |
| Current consumption : | 33mA @ 24V |
| Maximum contact load : | 16 A / 250 V AC (max) 16 A / 24 V DC (max) |
| Output : | 1 x NO/NC |
| Main features : | mounting on DIN, TS-35 rail LED indication Bistable operation controlled by controlled output S |
| Working temperature : | -20 °C ... 50 °C |
| Weight : | 0.065 kg |
| Dimensions : | 97 x 17 x 65 mm |
| Manufacturer / Brand : | ORN |
| Warranty : | 2 years |
